Nylon vs ABS: Which is Better for Your Project

Published: October 28, 2024Last Updated on: January 7, 2025

Explore the pros and cons of Nylon vs ABS for 3D printing, including their properties, advantages, and ideal uses in various industries.

Introduction

When it comes to 3D printing, the choice of filament material is crucial. Two of the most commonly used materials are Nylon and ABS.

In this blog, we will compare and contrast these two materials, focusing on their key differences in terms of strength, flexibility, and durability.

Overview of Nylon and ABS

Nylon is a popular 3D printing material known for its high strength, toughness, and durability.

Nylon parts have a smooth, glossy finish and can be easily sanded and painted. Nylon is also resistant to heat, chemicals, and abrasion.

ABS (Acrylonitrile Butadiene Styrene)

ABS is another common 3D printing material known for its rigidity, impact resistance, and easy printing. ABS parts have a slightly rougher surface texture, but they can be post-processed and smoothed out. ABS is also resistant to heat and chemicals, although not as much as Nylon.

In the following sections, this guide will break down the key differences in these material properties in clear terms.

Comparison: Nylon vs. ABS

Here's a table summarizing the key differences between Nylon and ABS:

Property	Nylon	ABS
Strength and Durability	Higher tensile strength, more durable	Relatively strong but less durable
Flexibility and Elasticity	More flexible, can bend and flex without breaking	More rigid, less flexible
Temperature Resistance	Higher heat resistance, can withstand higher temperatures	Lower heat resistance, may warp or degrade at lower temperatures
Chemical Resistance	Better resistance to a wider range of chemicals	Less resistant to chemicals
Ease of Printing	More challenging to print, prone to warping and adhesion issues	Easier to print, less prone to warping and adhesion issues
Cost	More expensive	Less expensive

In summary, Nylon offers superior performance in terms of strength, flexibility, and environmental resistance, making it a better choice for demanding applications.

However, Nylon can be more challenging to print compared to the more user-friendly ABS.

3D Printing with Nylon

Printing Requirements

Printing Nylon requires a heated build plate (80-100°C) and an enclosed printer environment to maintain consistent temperature.

Challenges in Printing

Nylon's high thermal expansion can lead to warping and shrinkage during printing. This needs to be carefully managed.

Best Practices for Nylon Printing

Use a heated build plate and adhesive to improve part adhesion
Slow down printing speed, especially for the first few layers
Utilize cooling fans judiciously to minimize warping
Optimize your Nylon printing profile for your specific printer and needs
Post-process Nylon parts through sanding, drilling, or painting

By following these guidelines, you can successfully print high-quality Nylon parts that take advantage of the material's superior strength, flexibility, and durability.

3D Printing with ABS

Printing Requirements

Printing ABS requires a heated build plate (90-110°C) and an enclosed printer environment to maintain consistent temperature.

Challenges in Printing

ABS is prone to warping due to its high shrinkage rate. It also produces strong fumes during printing that need to be managed.

Best Practices for ABS Printing

Use a heated build plate and adhesive to improve part adhesion
Slow down printing speed, especially for the first few layers
Utilize cooling fans judiciously to reduce warping
Ensure proper ventilation and containment to manage fumes
Post-process ABS parts through sanding, painting, or other finishing techniques

Following these best practices can help overcome the common challenges of printing with ABS and produce high-quality 3D printed parts.

Advantages and Disadvantages of Nylon

Pros:

High Strength: Nylon is significantly stronger than ABS, making it suitable for parts that need to withstand heavy loads or impact.
Flexibility: Nylon's flexibility allows it to bend and flex without breaking, which can be beneficial for parts that require some give or movement.
Chemical Resistance: Nylon has excellent resistance to a wide range of chemicals, making it suitable for harsh environments.

Cons:

Moisture Absorption: Nylon can absorb moisture from the air, affecting its dimensional stability and mechanical properties.
Cost: Nylon is generally more expensive than ABS.
Printing Difficulty: Printing with Nylon can be more challenging than ABS, requiring a heated build plate and careful management of warping and adhesion.

Advantages and Disadvantages of ABS

Pros:

Affordability: ABS is generally less expensive than Nylon, making it a more budget-friendly option for 3D printing projects.
Heat Resistance: ABS has good heat resistance, making it suitable for parts that may be exposed to moderate temperatures.
Ease of Printing: ABS is easier to print compared to Nylon, with fewer issues related to warping and adhesion.

Cons:

Flexibility: ABS is a more rigid material than Nylon, which can be a disadvantage for parts that require some flexibility or movement.
Warping: ABS is prone to warping during the printing process, which can be challenging to manage and may result in deformed or inaccurate parts.
Fumes: ABS can emit strong fumes during the printing process, which requires proper ventilation and air filtration to ensure a safe working environment.

Best Applications for Nylon

Industrial Uses

Nylon's exceptional strength, durability, and chemical resistance make it an excellent choice for industrial applications that require robust and high-performance components.

This includes manufacturing tools, machinery parts, and other industrial equipment that needs to withstand heavy loads, impact, and harsh environments.

Functional Prototypes

The combination of Nylon's strength, flexibility, and heat resistance makes it an ideal material for creating functional prototypes that can be thoroughly tested and evaluated before final production.

Nylon prototypes can accurately simulate the performance and behavior of the final product, allowing for more efficient and cost-effective product development.

Best Applications for ABS

Prototyping

ABS is a popular choice for 3D printing prototypes due to its relative ease of use and the ability to produce parts with a good level of detail and finish.

ABS prototypes can help designers and engineers quickly validate concepts and gather feedback before moving to final production.

Everyday Items

The rigidity and impact resistance of ABS make it a suitable material for producing a variety of everyday consumer products, such as household items and toys.

ABS's combination of affordability and moderate performance makes it a practical choice for these types of applications.

Nylon vs ABS: Which Should You Choose?

Strength and Durability:

If you require a strong, durable, and impact-resistant material, Nylon is the better choice.

Nylon's superior strength and flexibility make it suitable for industrial applications, functional prototypes, and parts that need to withstand heavy loads or stress.

Flexibility and Mobility

For parts that need to flex, bend, or move, Nylon's flexibility gives it an advantage over the more rigid ABS.

Applications like hinges, living hinges, and mechanical components may benefit from Nylon's unique properties.

Cost and Ease of Printing

If your project has a tighter budget or you're new to 3D printing, ABS may be the more cost-effective and easier-to-print option compared to Nylon, which can be more challenging to work with.

Recommendations

For industrial applications, functional prototypes, and parts that require high strength and durability, Nylon is the recommended material.

For everyday consumer products, simple prototypes, and parts where cost and ease of printing are more important than maximum performance, ABS may be the better choice.

Conclusion

In this post, we've compared the key differences between 3D printing with ABS and Nylon.

ABS is an affordable and relatively easy-to-print option, suitable for everyday products and simple prototypes. However, it's less flexible and more prone to warping than Nylon.

Nylon offers superior strength, flexibility, and chemical resistance, making it ideal for industrial uses and functional prototypes. But it can be more challenging to print and more expensive.

The right choice depends on your unique application - consider all relevant factors to determine whether ABS or Nylon is best for your project.
